Grapthec Pro Studio
It is the software for creating original designs and has enhanced functions such as auto-shapes, shading, and editing functions. It is like the popular graphics design software as the Adobe Illustrator and CorelDRAW. It can also configure the cutting conditions and other settings on the plotter. Importing of EPS, Ai, CMX, and PDF file types are supported. Graphics created with other popular design software can be imported into this software.
1967 Shelby GT500 Barn Find and Appraisal That Buyer Uses To Pay Widow - Price Revealed - Duration: 22:15. Jerry Heasley Recommended for you. It is the software for creating original designs and has enhanced functions such as auto-shapes, shading, and editing functions. It is like the popular graphics design software as the Adobe Illustrator and CorelDRAW. It can also configure the cutting conditions and other settings on the plotter.
Supported OS : Windows10 / 8.1 / 8 / 7
Major features of Graphtec Pro Studio
Creating the registration marks.
The registration marks can be added into the arts board of the design application software. It can be selected from 10 patterns according to the design object size and the precision of axis alignment in the Print & Cut applications.
Tiling (split the object)
The cutting object can be split into smaller tiles. When the object needs to be placed to the surface made by multiple panels or is larger than the width of the media, the object can be split to size for fit it.
Matrix copy
It is used for creating multiple copies of the same object. The object is copied in specified matrix condition.
Weed lines and border
The border line and weeding lines can be added around the cutting object automatically and then it is cut. It makes easier to remove the excess material from the media.
Tool assignment
Graphtec Pro Studio is able to assign the tool condition to the each color or the layer. The settings of tool condition as force, speed, quality (acceleration) and others can be set for the each color or the layer. It can be performed in a single job by process of different types.
Supports newest ARMS 6.0 on FCX2000
It supports ARMS (Advanced Registration Mark Sensing system) 6.0. New functions such as supporting processing on the reverse side, reversed color mark are available. It enables to enhance usability
Show Details
Offline operation using the USB flash memory
Plot data is created from the design by using Cutting Master 4, then it is saved to USB memory. The plot data file can be selected from the USB on the plotter, then cutting is performed. This simplified work-flow enables users to operate without a computer.
[Compatible models] CE LITE / FCX4000 / FCX2000
Data management using bar-code with USB flash memory
In Print & cut operation, the plot data is automatically selected from USB flash memory by scanning the bar-code printed on the media. Bar-code is created by using Graphtec Pro Studio. This prevents the usage of incorrect data, and improves work efficiency.
[Compatible models] CE LITE / FCX4000 / FCX2000
Copy of data with registration marks
After data is sent the first time, it can be copied multiple times without a PC.
[Compatible models] CE LITE / FCX4000 / CE6000 PLUS / FCX2000 / FC8600 / FC4500
In the FCX2000 / FCX4000, the first four marks are scanned on the first sheet, and only the first mark in subsequent sheets. Graphtec Pro Studio is able to configure FCX2000 / FCX4000 to execute copy in this condition. This improves productivity by shorting scan detection time.
Reverse side Cutting/Creasing using registration marks
Cutting and creasing can be aligned to the printed graphics even if processing is performed on the reverse side of the media. This prevents any scratches or damage to the printed graphic. Graphtec Pro Studio is able to configure FCX2000 to execute the process in this condition.
[Compatible models] FCX4000 / FCX2000
Expanded cutting area
It expands the cutting area to include objects outside of the area enclosed by registration marks. Production efficiency is enhanced by reducing media waste.
[Compatible models] CE LITE / FCX4000 / CE6000 PLUS / FCX2000 / FC8600
Creating registration marks in reversed color
The Cutting Master 4 is able to create the registration marks either one of the normal style or reversal style. The reversal style mark has the reversed color and it is able to detect the mark on the media such as the type of glossy or shiny. It enables to expand the compatible media for the Print & Cut applications.
It able to specify the color of registration mark line and the color of paint around mark after software version 2.10.
(A model that supporting color mark: CE LITE-50)
[Compatible models] CE LITE / FCX4000 / CE6000 PLUS / FCX2000 / FC8600
Lines pattern
It can set configuration of line intuitively to plot such as style, width, corner, color, join, end cap, and position.
[Compatible models] CE LITE / FCX4000 / CE6000 PLUS / FCX2000 / FC8600
Outline
It creates new lines (paths) in specified space from the object.
Combine objects
It can edit the overlapped objects using the effects function into a single object or multiple objects.
Fill
It can easily paint colors on a object in the illustration and can also fill in a gradient or pattern.
Enga veetu ip pilai mgr mp3 songs.
Auto-trace
The imported bitmap (raster) images is able to be converted into vector objects. There is a powerful noise reduction function.
Dwonload video naruto full epispde. Imports Adobe Illustrator/CorelDRAW file
It supports the importing of files in the ai format, cmx format, and others into Graphtec Pro Studio. Graphics created with popular design software such as Adobe Illustrator or CorelDRAW can be imported without converting the file format. The cutting job can be performed using only Graphtec Pro Studio even if the design is created using Adobe Illustrator or CorelDRAW by a designer.
